Intrinsically safe sound alarm YO3IS – 100 dB (A)
- Maximum sound power
100 dB (A) / 1 m
- IP55 standard
- 32 selectable tones in accordance with international regulations
- Sound selection by DIL switch
- Stainless steel fasteners
- Monitoring mechanism
- Fireproof ABS housing
100 dB (A) / 1 m
- IP55 standard
- 32 selectable tones in accordance with international regulations
- Sound selection by DIL switch
- Stainless steel fasteners
- Monitoring mechanism
- Fireproof ABS housing
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
Yodalex range sound signal designed for use in hazardous environments.
This unit should be used in conjunction with an approved Zener barrier or galvanic insulator. This product line should only be powered by a Zener barrier or an approved galvanic insulator. Powering these devices without a proper nominal value barrier can damage these products and cancel any protection.
Maximum sound output 100 dB (A) / 1 m
IP55 rated as standard
32 Selectable tones responding to international regulations
Sound selection via DIL switch
Stainless steel fasteners
Monitoring facility
Zone 0, 1, 2, 20, 21, 22
References Manufacturer: 205308,207019
| Ambiant temperature | -20 ° C to 40 ° C |
|---|---|
| Temperature class | T6 |
| Feed | 12-48V DC |
| Waterproofing protection (IP) | Ip55 |
| Application / usage | ATEX zone |
| ATEX zone | Zone 1/2 |
| Gas class | IIC |
| ATEX protection mode | Ex e (increased security) |
| Certificates | ATEX.IECEx.UKCA |
| Material | PC / Flated ABS |
| Body colors | Red |
| Ranting power | 110db |
| Fireproof ABS | 1 |
| 12V AC / DC | 1 |
| 100db | 1 |
