PUSH PUSH PUSH PB125 stainless steel
- IP66,67
- Ambient temperature: -40 ° C to + 55 ° C
- Zone 1.2
- Net weight - 4.7 kg
- Control Type Unit - Automatic Reset or Push Pull Button
- Ambient temperature: -40 ° C to + 55 ° C
- Zone 1.2
- Net weight - 4.7 kg
- Control Type Unit - Automatic Reset or Push Pull Button
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
The PB125 Anti-Screening Manual pushbutton is ATEX / IECEX certified for use in potentially explosive atmospheres. It can trigger alarms to alert potential hazard personnel, report the need for immediate emergency response, and much more.
References Manufacturer: PB125
| Ambiant temperature | -40°C to +55°C |
|---|---|
| Temperature class | T6 |
| Warranty | 3¨ |
| Feed | max. 500 V AC. 250V DC |
| Waterproofing protection (IP) | Ip66.ip67 |
| Application / usage | ATEX zone |
| ATEX zone | Zone 1/2 |
| Gas class | IIC |
| ATEX protection mode | Ex d (explosion) |
| Certificates | Atex.iecex |
| Frequency (Hz) | 50 / 60hz |
| Material | 316L Stainless Steel |
| Certificat_atex-en_us | 13 ATEX 1563X |
| Certificat_iecex-en_us | IECEX NEM 13.0033X |
| Body colors | Red (RAL3001) |
| Light source | LED |
| LED indicator | 1¨ |
