Aluminium alloy junction boxes for zone 1, 2, 21, 22
CTBE
- Zone 1, 2, 21, 22
- 19 different sizes
- IP66
- Stainless steel AISI 316L
- Stainless steel bolts and screws
- EPDM gasket
- Internal/external earth screws
- Fixing legs
- Security policy
- Delivery policy
The CTBE series economical junction boxes, made of stainless steel, are suitable for electrical installations placed in aggressive environments and used as augmented or intrinsic safety boxes. They can be supplied with multipolar or modular boundaries and can be drilled according to the customer’s specifications.
Data sheet
- Certification
- ATEX
Iecex - Suitable for
- Area 1/21
- Protection mode
- Ex e
Ex tb - Degree of protection
- IP66
- Material
- Stainless steel AISI 316L
- Frequency
- 50/60 Hz
- Rated current
- 8 - 400 [A]
- Terminal section
- 1.5; 2.5; 4; 6; 10; 25; 35; 70; 95; 120; 185; 240; 300 [mm2]
- Gaskets
- Silicone acid/hydrocarbon and high temperatures resistant
- Bolts and screws
- Stainless steel Entries: 2 ISO M25 entries
- Mounting type
- AISI 316L stainless steel welded feet
