Horus Series Anti-Screening Phone
- Protection against explosions:
II 2G EX E IB [ib] MB IIC T4 GB
II 2D EX IB [ib] TB IIIC T135 ° dB
- Zones 1, 2, 21, 22
- Housing material: fiberglass reinforced polyester (GRP)
- Yellow, red or black colors
- Handset material: thermosetting resin compound
- Keyboard keyboard stainless steel 20 keys
- Operating temperature: -45 ° C to + 70 ° C
- weather resistance: IP66
- Stridge tone ringtone 95 dBA at 1 meter typical
- relative humidity up to 95% (without condensation)
- M.T.B.F. more than 50,000 hours of use
- Crochet switch life> 1,000,000 operations
II 2G EX E IB [ib] MB IIC T4 GB
II 2D EX IB [ib] TB IIIC T135 ° dB
- Zones 1, 2, 21, 22
- Housing material: fiberglass reinforced polyester (GRP)
- Yellow, red or black colors
- Handset material: thermosetting resin compound
- Keyboard keyboard stainless steel 20 keys
- Operating temperature: -45 ° C to + 70 ° C
- weather resistance: IP66
- Stridge tone ringtone 95 dBA at 1 meter typical
- relative humidity up to 95% (without condensation)
- M.T.B.F. more than 50,000 hours of use
- Crochet switch life> 1,000,000 operations
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
Horus-based explosionphones are designed to provide safe and reliable communication in ATEX areas. The phones have been developed to operate in the petrochemical industry, usually used in the production, transport and refining of oil, natural gas, coal, etc. The housing is made from shock-resistant GRP and shocks and even acids, alkalis and lubricants. Its robust design offers a perfect envelope meet the highest requirements for analog or VoIP phones, combined with proven reliability for critical mission communications and high security applications. It is designed to provide ultimate comfort of use on the basis of industrial standards and decades of leading expertise and know-how on the market. The telephone device has a screen with integrated heating for environments at very low temperatures.
References Manufacturer: FRA0038-001, FRA0038-002, FRA0038-003, FRA0038-004, FRA0038-005, FRA838-006, FRA0038-007, FRA0038-008, FRA0038-009, FRA0038-010, FRA0038-011, FRA0038-012
| Ambiant temperature | -40 ° to + 70 ° |
|---|---|
| Temperature class | T6 |
| Warranty | 3¨ |
| Feed | 24-48V DC |
| Waterproofing protection (IP) | Ip66 |
| Application / usage | ATEX zone |
| ATEX zone | Zone 1/21 |
| Gas class | IIC |
| ATEX protection mode | Ex i (intrinsic safety) |
| Certificates | Atex.iecex |
| Material | Reinforced polyester (GRP) |
| Body colors | Black |
| Ranting power | 92dB |
| Shock resistance index | Ik09 |
| Cable entry (s) | 2xm20 |
| Mounting type | Projecting |
| Protocol | SIP 2.0 |
| Keypad | 1¨ |
| Handset | 1¨ |
| Cord type | Armed |
| Technology | Analogic |
| POE | 1 |
| VoIP | 1 |
| Orange | 1 |
