List of products by brand Nugelec
ECA 200 Control and Signaling Equipment
€0.00
Tax excluded
Main features:
- Integrated Alarm Management Unit (UGA)
- 2, 4 or 8 lines of 32 manual call points or automatic detectors
- Integrated power supplies and batteries
Ref. : NUG31020
ECA 200 Control and Signaling Equipment
Ideal for small establishments requiring a conventional fire detection system and some safety functions (hotels, boarding schools, etc.). The entire ECA range is used to manage the evacuation of the building as part of a type 1 Alarm Equipment.
NUG31020 - ECA 202
Data sheet
- Panel type
- ECS
- Certification
- EN54-23
- Loop number
- 2
4
8 - System type
- Conventional
ECA 3008 Control and Signaling Equipment
€0.00
Tax excluded
Main features:
- Integrated Alarm Management Unit (UGA)
- 8 lines of 32 manual triggers or automatic detectors
- 2 Lack of Voltage safety zones
- Provide external power supply for the servos
Ref. Manufacturer: NUG31071
Panel Type 1 ECA - equipped with 8 Loops - with UGA and CMSI
Ideal for small establishments requiring a conventional fire detection system and some safety features (hotels, boarding schools). The whole of the ECA range makes it possible to manage the evacuation of the building within the framework of a Type 1 Alarm Equipment. The ECS/CMSI versions also make it possible to manage the security of the establishment -fire, smoke extraction, etc.).
SCA00076
Data sheet
- Panel type
- ECS
- Implementation
- Fire (acc. EN54)
Industry - Certification
- EN54-23
- Loop number
- 8
- System type
- Conventional
Control and Safety Equipment SEMSEA.EC
€0.00
Tax excluded
Designed for installations in buildings requiring a category A fire detection system, addressable.
Data sheet
- Panel type
- ECS
- Certification
- EN54-23
- Loop number
- 8
- System type
- Addressable
Addressable Thermovelocimetric Detector DTV A3000
€0.00
Tax excluded
Main features:
- Operating voltage: 18 to 30 Vdc
- Standby current under 24 V: 220 uA
- Current under alarm at 24 V: 5 mA
- Average coverage: 50 m2
- Operating temperature: -10 to 50°
MFR ref.: NUG30253
Thermovelocimetric detector allowing the detection of a temperature higher than 60°C or a rise in temperature of 8°C/min.
Data sheet
- Technology
- Temperature
- Implementation
- Fire (acc. EN54)
Industry - Certification
- NF
- Power supply
- 18-30 Vcc
Flame detector UV/IR-210/1CZ
€0.00
Tax excluded
OGGIONI flame detectors use a microprocessor for the analysis of sophisticated electronic signals.
The UV/IR and IR3 flame detector uses the analysis of the flame flicker frequency as an additional alarm criterion. UV/IR and
IR3 flame detectors have good false alarm rejection. UV is immune to virtually all false alarm sources except arc welding. .
12-24 VDC (10-28 VDC) power supply
Normal Current 25 mA at 24 VDC
Alarm in progress, at 24 Vdc +/- 75 mA per 24 Vdc
Startup time <10 s
Alarm output setting LED and selectable relays latch/no latch, factory setting: latch
Standard current output available 0-20 mA (stepped, sinking, non-isolated)
Alarm response time <10 sec.
Cone of vision of at least 90°
Glass-reinforced polyester (GRP) housing, cover screw tightening torque 2 nm minimum
IP65 ingress protection
Operating temperature Da -40 °C to +70 °C (da -40 °F to +158 °F)
Ambient temperature ATEX and FM 3611: -25 °C to +70 °C (-13 °F to +158 °F)
Automatic and manual automatic sensor test (integrated automatic test) and manual self-test
Dimensions 125 x 80 x 57 mm (4.9 x 3.15 x 2.25 in)
Weight: 465 gr (1.05 lb)
M20 cable gland (cable conduit diameter 5.5-13 mm, two stages 5.5-8 mm and 8-13 mm)
Data sheet
- Certification
- ATEX
EN54-10 - Operating temperature range
- -40 to +70°C
Conventional Optical Smoke Detector DOF S3000
€0.00
Tax excluded
Main features:
- Operating voltage: 15 to 30 Vcc
- Running under 24 V: 70 UA
- Running under alarm 24 V: 25 mA
- Average cover: 50 m2
- Operating temperature: 0 to 50 °
Ref. manufacturer: NUG30246
The optical smoke detectors are equipped with an optical sensor to detect the particles present in the smoke, by reflection effect. This type of detector is particularly effective in detecting fires with smoke release containing visible combustion particles.
Maximum reactivity in the event of a slow combustion fire or sewing fires that release large visible smoke particles.
SCA00067
Data sheet
- Technology
- Optical smoke
- Implementation
- Fire (acc. EN54)
Industry - Certification
- EN54-23
- Ambiant temperature
- 0°C to 50°C
- Power supply
- 15-30 Vcc
Conventional opto-thermal detector DMCF S3000
€0.00
Tax excluded
Combined detector or multi-sensor opto-thermal which integrates 2 technologies and allows the detection of two effects characterizing the start of a fire.
Data sheet
- Technology
- Opto-thermal
- Implementation
- Fire (acc. EN54)
- Certification
- NF
- System type
- Conventional
Flame detector IRY2
€0.00
Tax excluded
Main features:
- Size: 104 x 42mm
- Weight: 125g
- White colour
- IP20
- Operating temperature: -10°C to 55°C
- red LED
- Material: ABS AE
- Conventional infrared
- Viewing angle: 45°
- Certification: CE DPC NF
The IRY2 detector is a conventional Class II certified NF Class II infrared flame detector that uses the medium infrared spectrum.
It consists of fire safety systems for the protection of premises containing liquid or gas flammable substances. It is a conventional infrared flame detector for detection tables.
Data sheet
- Implementation
- Industry
- Certification
- NF
- Suitable for
- non-Ex
- System type
- Conventional
Solista LX Visual Diffuser
€0.00
Tax excluded
Main features:
- LED strobe light technology for long life and low power consumption
- Coverage volume up to 7.5 m (switchable up to 2.5 m)
- 0.5 or 1 Hz flash rate (switches to 0.5 Hz to reduce power consumption)
- Easy installation
- IP33C (shallow base) and IP65 (deep base) protection
- White or red body
- White or red flashing strobe light options
- Certified to EN54-23, NF, VdS, CNBoP and AS standards
MFR ref.: NUG30493
The Solista LX range of flashing beacons are suitable for a wide variety of applications where a visual signaling device is required. The beacon features a patented lens design that distributes light to achieve the required illumination specified by EN54-23, while using minimal current consumption. Available in a red or white body and compatible with the full range of 6 bases.
Data sheet
- Panel type
- visual diffuser
- Certification
- EN54-23
NF - Degree of protection
- IP 33
Test lamp for flame detectors TC-169/1
€0.00
Tax excluded
The OGGIONI TC-169/1 non-EX flame detector test lamp activates OGGIONI 210 series flame detectors;
UV/IR-210/1, UV-185/5 and IR3-109/1. For all models, the detection range is 4 meters (13 ft). The TC 169/1 test lamp is not EX and may only be used in safe areas.
Fixed flame detector IRY2
€0.00
Tax excluded
The IRY2 detector is a conventional class II infrared flame detector certified NF.
Data sheet
- Certification
- EN54-10
UL - Degree of protection
- IP 21
- System type
- Conventional
- Operating temperature range
- -10°C to 55°C
Control and Signaling Equipment ECA 4008
€0.00
Tax excluded
Main features:
- Integrated Alarm Management Unit (UGA)
- 8 lines of 32 manual triggers or automatic detectors
- 4 undervoltage or voltage emission safety zones
- Signaling unit (4 series of 3 lights)
- Provide external AES power supply for servos and sirens
Ref. Manufacturer: NUG31067
Type 1 ECA switchboard - equipped with 8 loops - with UGA and CMSI ET/MT 4 lines
Ideal for small establishments requiring a conventional fire detection system and some safety features (hotels, boarding schools?). The whole of the ECA range makes it possible to manage the evacuation of the building within the framework of a Type 1 Alarm Equipment. The ECS/CMSI versions also make it possible to manage the security of the establishment -fire, smoke extraction, etc.).
SCA00077
Data sheet
- Panel type
- ECS+CMSI
- Implementation
- Fire (acc. EN54)
Industry - Certification
- EN54-23
- Loop number
- 8
- System type
- Conventional
Adressable optical smoke detector DOF A3000
€0.00
Tax excluded
Main characteristics :
- Operating voltage: 18 to 30 Vdc
- Standby current at 24V: 220 μA
- Current in alarm under 24V: 5 mA
- Logo color: black
- Operating temperature: 0 to 50°C
- Admissible humidity without condensate. : 0% to 95%
- cover avg. : 50 m² – Certification number: L 048 A0
- Reference standards: EN 54-7
A range adapted to each risk: From the optical smoke detector to the rate of rise detector via the Multisensor detector, NUGELEC offers a complete range, addressable (A3000 detectors) or conventional (S3000 detectors), adapted to each type of risk.
Optical smoke detectors are equipped with an optical sensor to detect the particles present in the smoke, by reflection effect.
This type of detector is particularly effective in detecting fires with the development of smoke containing visible combustion particles.
Data sheet
- Technology
- Multisensor
- Implementation
- Fire (acc. EN54)
- Certification
- NF
- System type
- Addressable
Addressable Multi-sensor Detector DMCF A3000
€0.00
Tax excluded
Main characteristics:
- Thin profile, to fit into all types of ceilings.
- Equipped with a two-color indicator (yellow/red) visible at 360° to easily identify a point in Alarm or in Fault.
- Passage of cables on the side of the detector or from the back.
- Anti-theft clip supplied with each base.
- Split wiring terminals to simplify the wiring of the detection lines
- Detector delivered with its protective cover to avoid any clogging during the work
- Automatic addressing
- Open line or loopback wiring
- Short circuit switch integrated in each detector
The opto-thermal multisensor detectors integrate two detection technologies: a thermal sensor and an optical sensor. They allow the detection of two effects that characterize a fire start: smoke onset and temperature rise. This detector allows early detection while avoiding untimely alarms in specific ambience areas.
Data sheet
- Technology
- Opto-thermal
- Implementation
- Fire (acc. EN54)
Industry - Certification
- NF
- System type
- Addressable
Conventional temperature rate-of-rise detector DTV S3000
€0.00
Tax excluded
Conventional thermometer detector DTV S3000
One-time detectors 3000
Thermo-velocimetric detector for temperature detection above 60°C or temperature elevation of 8°C/min
SCA00068
Data sheet
- Technology
- Temperature
- System type
- Conventional
VESDA Laser Focus
€0.00
Tax excluded
Designed for small surface installations, the VESDA Laser Focus is the smallest in its range. The model mentioned below provides surface monitoring up to 250m2. Provide an external SEA.
Data sheet
- Technology
- Aspirating smoke
- System type
- Addressable
Conventional
Solista Maxi Visual Diffuser EN54-23
€0.00
Tax excluded
EN54-23 light diffuser for delivering an evacuation signal intended for noisy premises.
Data sheet
- Panel type
- visual diffuser
- Certification
- EN54-23
NF - Degree of protection
- IP 33
Sounder DSAB3000 class B 90dB
€0.00
Tax excluded
Main features:
- Maximum volume 90 dB (A) / 1 m
- Degree of protection IP65
- Class B for broadcasting a fire escape sound conforming to standard NFS 32-001
- Its raised bottom leaves more room for wiring
- It comes with two rubber grommets
- Usable in type 1, 2a and 4 Alarm equipment
- NF SSI certified
- Reference standards: EN 54-3 and NFS 32-001
MFR ref.: NUG30450
The DSAB3000 is a versatile and reliable Conventional Fire Alarm Sounder (DS) suitable for all sound applications worldwide. Found in commercial buildings and security applications, its robust design also makes it suitable for use in the harshest environments.
The Sound Diffuser (DS) is NF certified according to standard EN 54-3. By incorporating a weatherproof enclosure capable of achieving IP65 weatherproofing and multiple mounting methods, the DSAB3000 is a suitable fire alarm Sounder (DS) for most installations.
It is a class B sound diffuser for broadcasting fire evacuation sound in accordance with the NFS 32-001 standard. Its raised bottom leaves more room for wiring. It comes with two rubber grommets. Can be used in type 1, 2a and 4 alarm equipment NF SSI certified Reference standards: EN 54-3 and NFS 32-001.
Data sheet
- Panel type
- Sound diffuser
- Implementation
- Industry
- Certification
- EN54-23
NF - Degree of protection
- IP 21
- Ambiant temperature
- -10°C to +50°C
- Power supply
- 10-60 Vdc
- Consumption
- – 10 V: 0.001 A (+/- 10%) – 24 V: 0.005 A (+/- 10%) – 48 V: 0.008 A (+/- 10%)
- Power output
- 90Db
- Dimensions
- 108 x 108 x 96mm
